T5 ELECTRO COMMAND™ - TIER 4A

A NEW BREED OF TRACTORS FOR FUTURE FOCUSED FARMERS

Features

MAXIMUM VERSATILITY

New Holland knows that the T5 will be used in a wide variety of applications, so it has been engineered by design to offer versatility as standard.

POWER AND PRODUCTIVITY

Powered by Common Rail engines that fully comply with the stringent Tier 4A emission regulations, you benefit from an impressive power to weight ratio for outstanding performance and impressive fuel economy.

ABSOLUTE DRIVING PLEASURE

Welcome to business class farming. The deluxe VisionView™ cab has been designed around you in virtual reality and is the fruit of extensive customer consultation.

EASE OF OWNERSHIP

As farmers, you want to spend more time working and less time maintaining your tractor, so the T5 has been designed to be ready whenever you are.

Gallery

MODELS

T5.95
Max. / Rated horsepower - ISO TR14396- ECE R120 (kW / hp)73 / 99
TransmissionElectro Command™
Max. lift capacity through the range (610 mm behind ball ends) (kg)2753
Min. width (mm)1913


Standard  Optional
T5.95
Engine*
Engine*F5C
No. of Cylinders / Aspiration / Valves / Emission level4 / T / 2 / Tier 4A
Fuel System - High Pressure Common Rail
Capacity (cm³)3400
Bore and Stroke (mm)99x110
Approved Biodiesel blendB20**
Max. / Rated horsepower - ISO TR14396- ECE R120 (kW / hp)73 / 99
Rated engine speed (rpm)2300
Max. torque - ISO TR14396 @1500 rpm (Nm)407
Torque rise (%)34
Engine Speed Management***
Diesel tank capacity (Litres)160
Service interval (hours)600
Electro Command™ transmission (40kph ECO)
Electro Command™ transmission (40kph ECO)
Powershuttle lever
Number of gears (F x R)16 x 16
Minimum speed (kph)2,27
IntelliShift™ System
Electro Command™ transmission [Optional Super Creeper (40kph ECO)]
Electro Command™ transmission [Optional Super Creeper (40kph ECO)]
Powershuttle lever
Number of gears (F x R)32 x 32
Minimum speed (kph)0,28
IntelliShift™ System
Electrical
12 volt alternator Standard120
Standard battery capacity (CCA / Ah)960 / 132
Axles
4WD front axle
Steering angle (°)60
Dynamic Front Fenders
Electro hydraulic 4WD engagement
Electro hydraulic diff. Lock engagement
Terralock™ functions
Turning radius (mm)4040
Hydraulics
Fixed Displacement
MegaFlow™ main pump flow / pressure @ 2300 rpm (Lpm / Bar)84 / 190
MegaFlow™ services pump flow / pressure @ 2300 rpm (Lpm / Bar)43 / 170
Electronic Draft Control (EDC)
Remote valves
TypeDeluxe
Max. no. rear valves / diverter / outlets3 / 1 / 8
Max. no. mid mount valves (Mechanical and Electro Hydraulic) / outlets2 / 4
Mid mount joystick control – Mechanical – (Electro Hydraulic optional)
Linkage
Rear linkage category2
Max. lift capacity at ball ends (kg)4527
Max. lift capacity through the range (610 mm behind ball ends) (kg)2753
Front linkage lift capacity at ball ends (through the range) (kg)1850
Front Loader Ready
Integrated loader joystick
PTO
Electro hydraulic PTO engagement
Soft Start PTO activation
Auto PTO management***
Engine speed at: 540 / 540E / 1000 (rpm)1938 / 1535 / 1926
Ground speed
Brakes
Hydraulic Trailer Brakes
Optional Pneumatic Tractor Brakes
Cab
Deluxe VisionView™ cab with FOPS - OECD Code 10 Level 1
Deluxe VisionView™ cab category level - EN 156952
High visibility roof hatch
Rear window wiper / washer
Auto Comfort™ seat with seat belt
Instructor seat with seat belt
Tilting steering column
Air conditioning
Air Recirculation Filters
MP3 Radio (with aux input socket)
Telescopic Shatterproof Mirrors
Comfort Ride™ cab suspension***
Fender mounted external PTO & Linkage controls
Cab monitor mounting bracket
Optimum Deluxe VisionView™ cab noise level - 77/311EEC (dB(A))74
Rotating Beacon
Weights
Minimum unballasted / shipping weights (kg)4350
Max. permissible weight (kg)7400
Dimensions
With rear tyres***16.9R30
Overall length inc. front support to rear linkage (mm)4161
Min. width (mm)1913
Height at centre of rear axle to top of cab Electro Command (mm)1940
Height at centre of rear axle to top of Comfor Ride™ suspension cab Electro Command (mm)1980
Min. overall height Electro Command Comfor Ride™ suspension cab (mm)2640
Wheelbase Electro Command (mm)2380
Track width (min. / max.) (mm)1430 - 2150
Ground clearance (mm)395

T5.105
Max. / Rated horsepower - ISO TR14396- ECE R120 (kW / hp)79 / 107
TransmissionElectro Command™
Max. lift capacity through the range (610 mm behind ball ends) (kg)3038
Min. width (mm)1913


Standard  Optional
T5.105
Engine*
Engine*F5C
No. of Cylinders / Aspiration / Valves / Emission level4 / T / 2 / Tier 4A
Fuel System - High Pressure Common Rail
Capacity (cm³)3400
Bore and Stroke (mm)99x110
Approved Biodiesel blendB20**
Max. / Rated horsepower - ISO TR14396- ECE R120 (kW / hp)79 / 107
Rated engine speed (rpm)2300
Max. torque - ISO TR14396 @1500 rpm (Nm)444
Torque rise (%)35
Engine Speed Management***
Diesel tank capacity (Litres)160
Service interval (hours)600
Electro Command™ transmission (40kph ECO)
Electro Command™ transmission (40kph ECO)
Powershuttle lever
Number of gears (F x R)16 x 16
Minimum speed (kph)2,27
IntelliShift™ System
Electro Command™ transmission [Optional Super Creeper (40kph ECO)]
Electro Command™ transmission [Optional Super Creeper (40kph ECO)]
Powershuttle lever
Number of gears (F x R)32 x 32
Minimum speed (kph)0,28
IntelliShift™ System
Electrical
12 volt alternator Standard120
Standard battery capacity (CCA / Ah)961 / 132
Axles
4WD front axle
Steering angle (°)60
Dynamic Front Fenders
Electro hydraulic 4WD engagement
Electro hydraulic diff. Lock engagement
Terralock™ functions
Turning radius (mm)4040
Hydraulics
Fixed Displacement
MegaFlow™ main pump flow / pressure @ 2300 rpm (Lpm / Bar)84 / 190
MegaFlow™ services pump flow / pressure @ 2300 rpm (Lpm / Bar)43 / 170
Electronic Draft Control (EDC)
Remote valves
TypeDeluxe
Max. no. rear valves / diverter / outlets3 / 1 / 8
Max. no. mid mount valves (Mechanical and Electro Hydraulic) / outlets2 / 4
Mid mount joystick control – Mechanical – (Electro Hydraulic optional)
Linkage
Rear linkage category2
Max. lift capacity at ball ends (kg)5420
Max. lift capacity through the range (610 mm behind ball ends) (kg)3038
Front linkage lift capacity at ball ends (through the range) (kg)1850
Front Loader Ready
Integrated loader joystick
PTO
Electro hydraulic PTO engagement
Soft Start PTO activation
Auto PTO management***
Engine speed at: 540 / 540E / 1000 (rpm)1938 / 1535 / 1926
Ground speed
Brakes
Hydraulic Trailer Brakes
Optional Pneumatic Tractor Brakes
Cab
Deluxe VisionView™ cab with FOPS - OECD Code 10 Level 1
Deluxe VisionView™ cab category level - EN 156952
High visibility roof hatch
Rear window wiper / washer
Auto Comfort™ seat with seat belt
Instructor seat with seat belt
Tilting steering column
Air conditioning
Air Recirculation Filters
MP3 Radio (with aux input socket)
Telescopic Shatterproof Mirrors
Comfort Ride™ cab suspension***
Fender mounted external PTO & Linkage controls
Cab monitor mounting bracket
Optimum Deluxe VisionView™ cab noise level - 77/311EEC (dB(A))74
Rotating Beacon
Weights
Minimum unballasted / shipping weights (kg)4350
Max. permissible weight (kg)7400
Dimensions
With rear tyres***16.9R34
Overall length inc. front support to rear linkage (mm)4161
Min. width (mm)1913
Height at centre of rear axle to top of cab Electro Command (mm)1940
Height at centre of rear axle to top of Comfor Ride™ suspension cab Electro Command (mm)1980
Min. overall height Electro Command Comfor Ride™ suspension cab (mm)2695
Wheelbase Electro Command (mm)2380
Track width (min. / max.) (mm)1431 - 2150
Ground clearance (mm)450

T5.115
Max. / Rated horsepower - ISO TR14396- ECE R120 (kW / hp)84 / 114
TransmissionElectro Command™
Max. lift capacity through the range (610 mm behind ball ends) (kg)3038
Min. width (mm)1913


Standard  Optional
T5.115
Engine*
Engine*F5C
No. of Cylinders / Aspiration / Valves / Emission level4 / T / 2 / Tier 4A
Fuel System - High Pressure Common Rail
Capacity (cm³)3400
Bore and Stroke (mm)99x110
Approved Biodiesel blendB20**
Max. / Rated horsepower - ISO TR14396- ECE R120 (kW / hp)84 / 114
Rated engine speed (rpm)2300
Max. torque - ISO TR14396 @1500 rpm (Nm)461
Torque rise (%)32
Engine Speed Management***
Diesel tank capacity (Litres)160
Service interval (hours)600
Electro Command™ transmission (40kph ECO)
Electro Command™ transmission (40kph ECO)
Powershuttle lever
Number of gears (F x R)16 x 16
Minimum speed (kph)2,27
IntelliShift™ System
Electro Command™ transmission [Optional Super Creeper (40kph ECO)]
Electro Command™ transmission [Optional Super Creeper (40kph ECO)]
Powershuttle lever
Number of gears (F x R)32 x 32
Minimum speed (kph)0,28
IntelliShift™ System
Electrical
12 volt alternator Standard120
Standard battery capacity (CCA / Ah)962 / 132
Axles
4WD front axle
Steering angle (°)60
Dynamic Front Fenders
Electro hydraulic 4WD engagement
Electro hydraulic diff. Lock engagement
Terralock™ functions
Turning radius (mm)4040
Hydraulics
Fixed Displacement
MegaFlow™ main pump flow / pressure @ 2300 rpm (Lpm / Bar)84 / 190
MegaFlow™ services pump flow / pressure @ 2300 rpm (Lpm / Bar)43 / 170
Electronic Draft Control (EDC)
Remote valves
TypeDeluxe
Max. no. rear valves / diverter / outlets3 / 1 / 8
Max. no. mid mount valves (Mechanical and Electro Hydraulic) / outlets2 / 4
Mid mount joystick control – Mechanical – (Electro Hydraulic optional)
Linkage
Rear linkage category2
Max. lift capacity at ball ends (kg)5420
Max. lift capacity through the range (610 mm behind ball ends) (kg)3038
Front linkage lift capacity at ball ends (through the range) (kg)1850
Front Loader Ready
Integrated loader joystick
PTO
Electro hydraulic PTO engagement
Soft Start PTO activation
Auto PTO management***
Engine speed at: 540 / 540E / 1000 (rpm)1938 / 1535 / 1926
Ground speed
Brakes
Hydraulic Trailer Brakes
Optional Pneumatic Tractor Brakes
Cab
Deluxe VisionView™ cab with FOPS - OECD Code 10 Level 1
Deluxe VisionView™ cab category level - EN 156952
High visibility roof hatch
Rear window wiper / washer
Auto Comfort™ seat with seat belt
Instructor seat with seat belt
Tilting steering column
Air conditioning
Air Recirculation Filters
MP3 Radio (with aux input socket)
Telescopic Shatterproof Mirrors
Comfort Ride™ cab suspension***
Fender mounted external PTO & Linkage controls
Cab monitor mounting bracket
Optimum Deluxe VisionView™ cab noise level - 77/311EEC (dB(A))74
Rotating Beacon
Weights
Minimum unballasted / shipping weights (kg)4350
Max. permissible weight (kg)7400
Dimensions
With rear tyres***16.9R38
Overall length inc. front support to rear linkage (mm)4161
Min. width (mm)1913
Height at centre of rear axle to top of cab Electro Command (mm)1940
Height at centre of rear axle to top of Comfor Ride™ suspension cab Electro Command (mm)1980
Min. overall height Electro Command Comfor Ride™ suspension cab (mm)2740
Wheelbase Electro Command (mm)2380
Track width (min. / max.) (mm)1432 - 2150
Ground clearance (mm)495
Back

Standard Optional  – Not available
* Developed by FPT Industrial
** Biodiesel blend must fully comply with the latest fuel specification EN14214:2009 and operation is in accordance with operator manual guidelines
*** Rear Tyres other than those mentioned are available: 600/65R34, 540/65R34, 520/70R34, 480/70R38, 480/70R34, 16.9 R34, 14.9R38, 13.6R38, 440/80R34 Nokian TRI2, 650/65-30.5 Trelleborg Grassland
