TK4 TRACTORS

Features

MORE THAN 85 YEARS OF EXPERIENCE

The result of more than 85 years of manufacturing experience in the crawler sector, the new TK4 series tractors.

AT HOME WITH APPLES, CHERRIES, GRAPES AND NUTS

Built for stability and traction, the all-terrain TK4 tractors are perfectly designed to climb the hills and mountains of fruit orchards, vineyards and nut groves.

INCREASED FRONT AXLE CAPACITY

The new TK4 track crawler machines can easily work with even bigger and heavier front implements thanks to the heavier, stronger front axle casting that permits the application of up to 1,100 lbs (500kg) of front ballast (TK4.100M only).

Gallery

HITCH AND HYDRAULICS

MAXIMUM POWER FOR HYDRAULIC FUNCTIONS

All TK4 models are equipped with a double pump open centre hydraulic system, capable of delivering the power required for hydraulic functions and steering separately, In larger Open Field models, a hydraulic pump capacity of 80 L / min. Specialty models can count on a hydraulic flow of 35.5 L / min, available as standard.


Read More

MULTIFUNCTIONAL AUXILIARY DISTRIBUTORS

Grouped rear right, auxiliary hydraulics with colour codes make it extremely fluid coupling. Some models can have up to five rear remote valves. On an auxiliary distributor it is possible to select a flow control valve, for tools that require a low flow of oil. The flow control valve can vary the oil flow from 9 to 45 L / min.


Read More

RUGGED THREE-POINT HITCH

Take on the largest implements for maximum productivity with big three-point hitch lift capacity – 3,535kgs on the TK4.80V and TK4.80F Specialty models, and 3,720kgs on the Open Field TK4.100 and TK4.100M.


Read More

LIFT-O-MATIC™ PLUS SYSTEM

Headland turns are made easy with the convenience of the Lift-O-Matic™ Plus system. One convenient lever allows you to completely raise or lower implements while maintaining position and draft settings. Minor draft adjustments can be made with just a push or a pull of the lever to fine tune your position.


Read More
