Advanced Pick-Up Fronts

PICK-UP SUCCESS

New Holland offers a pick-up front which guarantees smooth and speedy collection of crops which have been rowed by a New Holland Speedrower. No matter what the crop, whether grass seed, canola or beans, to name but a few, your New Holland front will gather wider windrows and save more valuable grains. Available in 4.55 metre grain configuration, it is fully compatible with CR and CX Elevation models. No matter the size or gradient of your field, this advanced pick-up front will clear them even faster.

UNIFORM FEEDING
The 660 mm diameter auger uses 12.7cm flights which means that even the heaviest windrows are efficiently transferred into the combine. What’s more, you can precisely adjust the auger both up and down to ensure that you have the perfect setting for the density of your windrows. This means that you can set a pre-determined level of auger float, from 1.6 - 3.2cm, to better deal with wedges of crop in uneven windrows. You can also control the speed of the auger to match your individual needs.
EXCELLENT FLOATATION
Just imagine what a full 30cm of flex could mean to you. Suddenly harvesting undulating fields becomes a delight. The entire frame flexes a full 30cm to enable you to follow the contours of even the roughest ground. The advanced Autofloat™ automatic floatation is standard. This uses a network of two sensors to provide consistent ground clearance across the entire pick-up width to guarantee uniform stubble height. The most demanding operations will choose the optional hydraulic flotation system, which delivers on-the-go front flotation adjustment from the comfort of the cab for the most uniform pick-up. The mechanical suspension can be adjusted with a simple wrench.
EFFICIENT AUGER PERFORMANCE
Auger speed has been increased to an impressive 212rpm on 4.55 metre fronts which, in some conditions, will enable a higher forward speed to enhance overall machine capacity. The auger features double ‘V’ pattern tines which ensure the crop is cleanly fed into the feeder, which together with the reduced clearance of the auger fingers, auger flight floor and auger clearance, will prevent wrapping, which means your in-field productivity will significantly improve as well as preventing potential damage whilst improving grain quality.
