T9 SERIES

When you pair the extreme power of New Holland T9 Series 4WD tractors with the precise control of the Auto Command CVT, you make your workday more comfortable and productive in the most demanding conditions. It provides faster acceleration to road speed at 1,650 engine rpm, and gives you maximum speed control. Use three adjustable target speeds to match your every need. Simply set your target speed anywhere between 91 cm per minute right through 40 kph and regulate it to the nearest 0.016 kph. No steps. No range changes. Just seamless speed changes to match the jobs you do, from seeding to hauling and running grain carts.

The T9 SmartTrax™ Series has been redefined with the addition of an all-new track system. This best-in-class solution features an automatic track tensioning system, track system suspension and oscillating roller wheels to deliver a smooth ride, support longer belt life and even wear, and eliminate the need for manual adjustments. Clear track system hubcaps help simplify maintenance, and the increased track belt offering meets a wide range of needs.

The Auto Command™ transmission allows for easier slow-speed operation, more precise speed control for high-value crops and added safety when backing up to hookup large implements. Using Auto Command saves you fatigue and fuel. You get automated efficiency without operator input, and can operate at peak power for any forward speed.

A heat-treated two-position agricultural solid bar is fitted to standard frame models. A heavy-duty Class 5 is offered on wide-chassis models. Max permissible tongue weight can reach up 6804 kg on Ag models and 9072 kg on scraper models, dependent on drawbar choice.

Auto Command™ responds to the amount of force you apply to the CommandGrip™ controller. Move the lever gently for gradual response, aggressively for quick response. Other controls are just as intuitive thanks to New Holland’s award-winning SideWinder™ II armrest with fully integrated IntelliView™ wide touchscreen display.
Select from four driving modes to suit your driving style:
• Auto Mode. Select the desired target speed and Auto Command matches the engine and transmission to maintain it.
• Cruise Mode. Set Auto Command to maintain a desired operating speed for economy and productivity.
• Manual Mode. Set the required engine and forward speed, independently of each other.
• PTO mode. As soon as the PTO is engaged, Auto Command guarantees a constant engine speed.

When you bring the tractor to a standstill, Auto Command™ prevents the tractor moving backwards or forwards, even with a heavy load. When you release the brake pedal, drive reengages and the transmission assures there is no risk of roll back on steep inclines. Imagine the efficiency you’ll gain when transporting or during frequent shuttling. That’s Active StopStart.

Available on all models, New Holland has toughened up its already proven Ultra Command full powershift transmission. Now with added strength and improved control, it is truly something special. It gives you the benefit of a new control system using the CommandGrip™ handle for fingertip access to ‘manual’ push button shifts and automated Ground Speed Management. A Hi-Lo dual power is fitted to gear 16, allowing you to quickly increase maximum transport speed from 30.5 to 40.2 kph.

New Holland T9 Series tractors can now be equipped with Low Side Wall (LSW) tires to meet the new demands of producers looking for high flotation, heavy pulling, and a narrow overall package for roading applications. LSW tires feature the ability to maintain high load ratings at 40% lower inflation psi values, opening new productivity value to a single tire combination. The larger rim diameter—without increasing the overall LSW tire diameter—results in a more stable tire for the toughest applications.

When equipped with LSW1250/35R46 singles, the overall width measures about 150 inches or 12.5 feet. This narrow roading width, in combination with a light footprint, provides a middle ground when choosing between SmartTrax™ and high-flotation duals. Low Side Wall tires design features a larger rim diameter without increasing the overall tire diameter, providing more stability for heavy pull and roading applications.

As the aspect ratio of a tire increases so does the chance for bouncing during roading and power-hop in in-field heavy pull applications. LSW tires eliminate those chances with a lower aspect ratio.

With LSW singles, total psi on the ground is comparable to high-flotation duals on tractors with similar gross vehicle weight — but yields a nearly 20% reduction in overall tire width.

The T9.700 with Ultra Command™ powershift set new benchmarks in drawbar fuel efficiency, drawbar horsepower and maximum pull when tested by an outside independent testing organization. In fact, tests found the complete T9 Series tractor line features power, torque and overall fluid efficiency that lead this tractor class, which means better productivity and reduced operating costs for you.

New Holland T9 Series tractors utilize the Row Crop frame on models up to the T9.580. When used in combination with VF Row Crop tires, they maintain load carrying capacities at lower air pressure ratings — producing less compaction, less fuel consumption to promote bottom line returns. High flotation duals can also be equipped with this technology, further improving fuel consumption in heavy-pull applications. Triples distribute the overall weight of the T9 Series tractor over even more area, decreasing compaction for your specific application.

The latest Ultra Command™ improvements reduce the time it takes to shift and shuttle. You can shift from gear 1 to 16 in 20% less time and shift from forward to reverse 38% faster. The result: Ultra Command uses less fuel, decreases operating costs and reduces fatigue.

Spring tillage, planting, post emergence side-dressing, grain carting, roading, and fall primary tillage—there is no application that a T9 Series tractor can’t handle.

Heavy-pull applications call for the High Power Frame matched with high-flotation tires. Tire designs featuring improved traction capabilities are made for these kinds of applications. Grain cart applications with VF dual tires (Row Crop Frame shown) allow for high-speed, low-pressure inflation, which lessens soil compaction while boosting fuel economy. Through less compaction, a T9 Series tractor improves your harvest and yields the following year.

With industry-leading peak horsepower range of 467 to 699, you get all the power and performance you need with our new models. Our T9 series 13-liter engine was upgraded to provide an additional 2% fuel efficiency, optimised torque levels in low gear operation and extended service intervals from 1200 hours to 1800 hours.

You’ll appreciate the fit and finish and automotive quality of the T9 Series cabs. The ergonomic, spacious, and practical environment is a must for day-long productivity.

• Deluxe Performance Cab Features: Cab suspension, rubber floor mat, standard steering wheel, cloth seat and semi-active suspension, cloth instructional seat, performance radio, electric mirrors with manual extension, luxury power ports, camera-ready
• Luxury Performance Cab Features: Cab suspension, rubber floor mat and carpet, leather-wrapped steering wheel, heated and ventilated leather seat and semi-active suspension, leather instructional seat, performance radio, electric mirrors with electric extension, luxury power ports, front and rear cameras

Our new T9 series received enhanced cab styling and comfort improvements including a redesigned exhaust system, enlarged windshield wiper arms, newly styled cab roof, four corner grab rails, LED lights, an upgraded sound system and much more.

T9 Series tractors offer sophisticated features that are easy and intuitive to access. The SideWinder Ultra armrest hosts all key controls, including throttle, transmission and hydraulics. Everything you need to control is intuitively selected. More advanced features can be quickly accessed.

• Customizable Buttons: Up to 11 buttons can be personalized and configured on the SideWinder Ultra armrest. Located in strategic positions around the armrest: one on the multifunction handle, two on both the joystick and main keypad, four on the rear keypad, and one or two on the throttle/transmission keypad (depending on the transmission option selected). These buttons can be configured to suit both the task at hand and the specific preferences of the operator.
• Adjustable SideWinder Ultra armrest: The SideWinder Ultra armrest can be adjusted to suit your specific requirements. Two manual levers adjust both the height and front/back position of the armrest for enhanced ergonomic operation.

The IntelliView™ 12 monitor delivers a wide range of machine benefits at your fingertips. A clear evolution from the former IntelliView IV, the new “12” model — with its sleek, automotive style “dash” styling, intuitive display and modern design — will become the benchmark of the future.

With precision technology, New Holland is unlocking a new level of connectivity and remote viewing never before seen in a 4-wheel-drive tractor. That’s the inherent advantage of a T9 Series tractor. In the T9 tractor, unmatched connectivity provides the ability to share information with your preferred providers, perform diagnostics remotely and make data-driven decisions related to your operations — all from any location and all designed to help you successfully manage your farm, fleet and data. You’ll accomplish more in a single day, work smarter and more efficiently, and enjoy a superior level of control and management of your entire fleet.

T9 Series tractors are available with standard or high-flow pumps, with up to 42 and 57 gpm (159 and 216 Lpm) capacities respectively. For demanding hydraulic applications, the optional MegaFlow™ pump delivers up to an extra 56 gpm (212 Lpm) of hydraulic flow to one bank of remotes, boosting total tractor flow up to a maximum of 113 gpm (427 Lpm). For total 113 gpm (427 Lpm) flow to all remotes for extremely high hydraulic demands like seeding and planting, choose the MegaFlow II option. A large coupler is available for applications that demand unrestricted oil flow.
