Backhoe Loaders

COMFORT AND VISIBILITY The C Series Backhoe Loaders give the operator comfortable seating while providing them with greater visibility. A layout of ergonomic and pilot controls both give the operator maximum productivity and comfort.

HIGH VERSATILITY The C Series Backhoe Loaders offer versatility with their wide-range of attachments that help the operator take on tougher jobs.

SUPERIOR BREAKOUT FORCES The design of the C Series Backhoe Loaders have straight arm loaders which produce unmatched lift capacity, bucket rotation, and breakout force.

PERFORMANCE This backhoe loader uses the curved boom design of big excavators which gives the operator superior digging performance. The backhoe design features in-line cylinders which also enhances its performance.

Backhoe Loaders

RIGHT FOR YOUR NEEDS

Many business operations will have a need for a loader that offers the versatility to do a lot more than just move bulk material. Typical alternative applications will include grading and leveling, the ability to grab heavy items such as trunks and concrete pillars plus a tractor unit with the traction and power to push materials or items into place or out of the way. With a 4 in 1 bucket, a backhoe loader will deliver this exceptional performance with just the one attachment. Choose a 6 in 1 bucket and you have the option to flip down adjustable pallet forks, ideal for handling palletized loads without the need for a dedicated vehicle. The backhoe can be equipped with a wide choice of buckets to match excavation, water course clearance, trenching and other demands. Post hole borers, hydraulic hammers and countless other tools can all be fitted. The long reach of both the standard and telescopic dipper, up to a massive 21.4 feet, allows long reach and digging depth comparable to many conventional dedicated excavators. Add to this the new revised cab featuring a new heated seat and up to ten LED lights and exterior side lights on the cab roof, there are no performance compromises with a New Holland backhoe loader.

Discover More

WELCOME ABOARD
A good cab will offer good operator comfort, excellent ergonomics and plenty of room to speed switching between loader and backhoe operation. A great cab will combine this with excellent all-round visibility, first class heating and ventilation with low noise and vibration levels. With the newly refreshed cab on New Holland backhoe loaders, you get all the small additional details that make the cab extra special. Room for tools and oddments as well as personal items. A high grip floor covering to help prevent the operator slipping when entering with muddy footwear. A powerful lighting package featuring up to ten optional LED lights giving true 360 degree light pattern thanks to the roof mounted side lights. Large retractable sunshades, cup holders, glove box and a deluxe pneumatic heated seat. To top it off, the engine exhaust pipe has been relocated to the right side of the cab to provide a clear view of the loader arm.
Discover More
POWERFUL ECONOMY
Choose between 98hp or 111hp, depending on model, the FPT Industrial F5H 3.4 litre four-cylinder engine in backhoe loaders is the same unit proven in New Holland T5 tractors. Complaint with stringent Tier 4B emission regulations, the engines have an advanced throttle control system. This allows the operator to adjust how the engine responds to throttle inputs from smooth to fast.
Discover More
POWERSHIFT™ OR POWERSHUTTLE, YOU DECIDE
New Holland offers its backhoe loaders with switchable two or four wheel drive, a Powershuttle forward / reverse mechanical transmission or automatic Powershift™ transmission. The all-wheel steer B115 C has equal size front and rear wheels with selectable front, all-wheel and crab steer modes.
Discover More
HYDRAULICS TO MEET EVERY DEMAND
To exactly match end user needs, New Holland backhoe loaders are offered with a choice of hydraulic pump designs. In addition, an auxiliary hydraulic circuit is available to power attachments to include hydraulic breakers and soil augers.
Two hydraulic pump designs are offered:

Twin gear pump
• Simple
• Constant flow
• Fast warm up
• Straightforward service and maintenance
• For general use. Suits applications with limited roading
• Maximum flow 40gpm @ 2200rpm
• Maximum operating pressure 205bar

Variable displacement pump
• Only active when there is a demand for oil
• Flow rate proportional to demand
• Reduces fuel consumption
• Reduced oil temperature due to flow on demand
• Ideal for intensive backhoe operation and frequent roading
• Variable flow from 6 to 43.5gpm
• Maximum operating pressure 205bar
Discover More
THE FIGURES TELL YOU EVERYTHING
With a New Holland backhoe loader, there is no compromise in performance. Dependent upon model, the front loader can be fitted with a front bucket of either 2.9ft³, 3.2ft³ or 3.77ft³ capacity and raise loads of 7451lbs.-7826lbs to heights of up to 11.5 feet. The backhoe has a digging depth down to 15.3 feet increasing up to 19.3 feet with the telescopic dipper. The bucket breakout force is as high as 5970daN, the dipper breakout coming in at 3225daN or 2390daN if extended. With a New Holland backhoe loader there is absolutely no compromise in performance.
Discover More
SPEND TIME SAVING MONEY
A key to equipment performance and longevity is routine care. New Holland has designed the backhoe loader so it takes the minimum of time to carry out routine checks. Service intervals are also fixed at 600 and 1000 hours, with easy access to all key fuel, engine, transmission and hydraulic filters. Extensive New Holland dealer network for full support is always handy.
Discover More
