T4 LP
PUT YOUR TRUST IN NEW HOLLAND TRACTOR DNA

T4 LP

white dots
COMPACT AND AGILE Light and compact, T4LP tractors are designed to offer the agility you would expect from this class of tractor.
COMPACT IN SIZE. BIG ON COMFORT New Holland continues to invest in dedicated research into operator comfort.
FOLDING ROPS AND LOW CAB HEIGHT Designed for use in orchards, olive groves and wide spaced vineyards, T4LP tractors have a lowered seat and folding ROPS frame to give an overall height as low as just 1,754mm or 2,274mm with the ROPS raised.
A CLEAR VIEW AHEAD Stylish design goes beyond great looks, New Holland has shaped the bonnet and fenders so they provide a clear view and a smooth surface to brush past branches and vines.
T4 LP

THE RIGHT MODEL FOR SPECIFIC DEMANDS

From the outset, New Holland developed the T4LP tractor to meet two diverse end user demands. The first are operators looking for a low height tractor for use in applications to include fruit production and viticulture in steep terrain. The second are operators working in mountainous areas where a low centre of gravity, good rear lift capacity and wide track stability are paramount. Offering good power to weight ratios, a low centre of gravity and a specification choice to suit specific demands, T4LP tractors make a versatile small tractor choice. With New Holland, versatility comes as standard.
DISCOVER MORE

Features

  • t4-lp-driveline-01

    COMPACT AND AGILE

    Light and compact, T4LP tractors are designed to offer the agility you would expect from this class of tractor. Thanks to a 55 degree turn angle, these 4WD drive tractors can deliver an un-braked turn radius as low as 4,000mm.In extreme terrain the standard front axle oscillation of 8 degrees can be increased to a maximum of 11 degrees for greater ground contour following.
  • t4-lp-transmission-01

    THE RIGHT RATIO FOR EVERY JOB

    To meet the diverse needs of end users, New Holland offers all T4LP models with a choice of one of six transmissions. Entry level 16x16 Shuttle Command™ offers working speeds as low as 700m/hr, the top specification 44x16 DualCommand™ with powershuttle lever,hi-lo gear splitter and creep speeds reducing this to just 170m/hr. Maximum travel speed is up to 40km/hr.
    DISCOVER MORE
  • t4-lp-engine-01

    SMOOTH FOUR-CYLINDER POWER

    Both the T4.75 and T4.85 are powered by four-cylinder 3.2 Litre turbocharged engines. Offering low fuel consumption, great refinement and a service interval of 600 hours, these engines also meet Tier 3 emission standards. The T4.95 and T4.105 also have four-cylinder turbocharged engines but of a different design and with a swept volume of 4.5 Litres. These outstanding power units offer low whole life running costs, are smooth running and can operate on 100% B100 biofuel. They are also Tier 3 compliant and offer 600 hour service intervals.
    DISCOVER MORE
  • t4-lp-operator-environment-01

    DESIGNED AROUND THE OPERATOR

    Operator comfort is a key New Holland priority. State of the art virtual simulation technology is employed to achieve the most ergonomic layout of the cab controls. This has resulted in an all new right hand console design, grouping all main hydraulic levers together for ease of operation. Noise and vibration levels are tightly controlled, with light steering and class leading visibility over the stylish engine hood all contributing to reduced operator fatigue.
    DISCOVER MORE
  • t4-lp-pto-and-hydraulics-01

    IN-BUILT STRENGTH

    Carried over from its T4 utility cousin, the front and rear axles on the T4LP have strength to accommodate the wider width, with a new cast front axle support. The rear axle has a capcity of 3,700kg, the rear linkages lifting 2,600kg. A 1,360kg capacity front linkage is available.
    DISCOVER MORE
MODELS

Explore available models

TECHNICAL SPECIFICATIONS
T4.75 LP

T4.75 LP

Rated Engine Power ISO TR14396 - ECE R120 @ 2300rpm [kW/hp(CV)]
57/78
16 x 16 Shuttle Command™ (30kph / 40kph)
Standard
T4.85 LP

T4.85 LP

Rated Engine Power ISO TR14396 - ECE R120 @ 2300rpm [kW/hp(CV)]
65/88
16 x 16 Shuttle Command™ (30kph / 40kph)
Standard
T4.95 LP

T4.95 LP

Rated Engine Power ISO TR14396 - ECE R120 @ 2300rpm [kW/hp(CV)]
71/97
16 x 16 Shuttle Command™ (30kph / 40kph)
Standard
T4.105 LP

T4.105 LP

Rated Engine Power ISO TR14396 - ECE R120 @ 2300rpm [kW/hp(CV)]
78/106
16 x 16 Shuttle Command™ (30kph / 40kph)
Standard

Technical specifications

New Holland Engine

New Holland Engine*
No. of cylinders / Capacity / Valves / Emissions Level
Turbocharged Intercooler
Approved biodiesel Blend
Rated Engine Power ISO TR14396 - ECE R120 @ 2300rpm [kW/hp(CV)]
Torque reserve (%)
Max. Torque ISO TR14396 (Nm)
Horizontal Exhaust / Vertical exhaust (Cab only)
Internal EGR
Fuel tank capacity (L)

Transmission

Front axle

Hydraulic system

PTO

Operator environment

Dimensions & Weights***

* Developed by FPT Industrial
** Conditions apply
*** Rear Tyres 340/85R28, 320/85R24 and 280/85R28
**** With driver (85kg) and full fuel tank
