T5 Auto Command™ & Dynamic Command™ - Gear up for efficiency with ultimate vision

THE POWER AND EFFICIENCY YOU’VE
COME TO EXPECT FROM NEW HOLLAND

T5 DYNAMIC COMMAND™ ＆ AUTO COMMAND™

PROVEN VERSATILITY The proven T5 range of tractors has been engineered by design to ensure that it productively accomplishes a whole range of agricultural applications – from field, loader and yard work through to high speed transport.

POWER AND PRODUCTIVITY This new four-model series, powered by FPT NEF four cylinder 4.5 Litre engines, offers maximum outputs ranging from 110 - 140hp.

THE BLUE POWER RANGE The T5.140 Dynamic Command™ & Auto Command™ models are available in premium Blue Power configuration.

THE BLUE DRIVING EXPERIENCE

The proven T5 range of tractors has been engineered by design to ensure that it productively accomplishes a whole range of agricultural applications – from field, loader and yard work through to high speed transport. This multipurpose range is available with either the new eight-speed semi-powershift Dynamic Command™ transmission or the renowned continuously variable, Auto Command™ transmission.

DISCOVER MORE

POWERED BY FPT INDUSTRIAL
New Holland is not going it alone when it comes to Stage V technology. They can draw on the experience of their in-house engine development group: FPT Industrial.
Pioneers: Fiat invented Common Rail technology in the 1980s and brought it to the masses in 1997 on the Alfa Romeo 156. They were the very first to introduce it on agricultural machines
on the TS-A tractor. Pioneering. Always.
Cleaner: for the eleventh consecutive year, CNH Industrial has topped the Dow Jones Sustainability World and Europe indexes for the Industrial Engineering sector. Cleaner Everywhere.
Proven: FPT Industrial has pioneered SCR technology since 1995 and has already produced more than 2.5 million SCR systems during the last fifteen years for the agricultural, construction and trucking industry. Reliability. Confirmed.
DISCOVER MORE
EIGHT-STEP SEMI-POWERSHIFT
The 24x24 Dynamic Command™ transmission enables you to shift between eight gears under load, without having to change ranges. Thanks to the wide spread of speeds within the three ranges, which correspond to those most frequently used whilst conducting in field or on road activities, you shouldn’t need to change range mid-task, which results in improved infield and on road productivity.
DISCOVER MORE
EFFICIENT AUTO COMMAND™ TRANSMISSION OFFERS ADVANCED NEW HOLLAND FEATURES
The proven T5 range of tractors has been engineered by design to ensure that it productively accomplishes a whole range of agricultural applications – from field, loader and yard work through to high speed transport. This multipurpose range is available with the renowned continuously variable, Auto Command™ transmission.
DISCOVER MORE
INTUITIVE INTELLIVIEW™ IV TOUCHSCREEN MONITOR
The IntelliView™ IV colour touchscreen monitor can be used to manage a whole host of advanced parameters and now features the all-new instant access touchscreen hub putting key operating parameters at your fingertips. Simply tap the parameter you wish to view, and it’ll appear.
DISCOVER MORE
THE ULTIMATE ERGONOMY AND COMFORT EXPERIENCE
The T5 Dynamic Command™ & Auto Command™ range now benefits from New Holland’s industry leading Horizon™ cab and all new Super High Visibility Roof Panel. Take a seat, relax and enjoy an immediate feeling of space, comfort and brightness, thanks to the 4-post concept, suspended seats and ample legroom.
In the yard, in the field or on the road, you have an uninterrupted, productivity enhancing view. Always. The single piece front screen offers a perfect view no matter what the weather or your field throws at you. The sun-visor protects you from the harshest rays. Whisper quiet comfort is courtesy of a mere 72dB(A) cab noise level.
DISCOVER MORE
HYDRAULIC POWER AND PTO FLEXIBILITY
Have you ever thought about just how much hydraulic flow you actually need? The T5 Dynamic Command™ range is fitted with an 80 litres/minute CCLS pump as standard, and an optional 110 litres/minute pump is also available which is standard on T5 Auto Command™ tractors. This is ideal for operations requiring the most intensive hydraulic flows. New Holland has engineered the CCLS system to operate at peak efficiency. The benefit? Full hydraulic power is always available at the remote valves and linkage, but only as much as is needed. The result? Reduced fuel consumption.
DISCOVER MORE
GREAT MANOEUVRABILITY. OUTSTANDING VISIBILITY. COMPACT PACKAGE.
The T5 Dynamic Command™ & Auto Command™ range has been designed with go-anywhere flexibility in mind, and this is translated by its compact overall dimensions. Standing at a mere 2720mm* tall it can slip into even the lowest livestock sheds. The low overall hood height of 1897mm provides extra visibility in all applications, but is invaluable when feeding livestock and loader work.

*540/65R34 tyres with Low profile roof
DISCOVER MORE
SUPER HIGH VISIBILITY ROOF PANEL
The all-new super high visibility roof panel makes it even more comfortable to work with loaders at full extension. It also adds to the light and bright nature of the cab, and takes the total glazed area to some 5.38 square metres.
DISCOVER MORE

MODELS

Explore available models

TECHNICAL SPECIFICATIONS

T5.110 DYNAMIC COMMAND™

Max. horsepower - ISO TR14396- ECE R120 [kW/hp(CV)]

81/110

Max. lift capacity at ball ends (kg)

5500

T5.120 DYNAMIC COMMAND™

Max. horsepower - ISO TR14396- ECE R120 [kW/hp(CV)]

88/120

Max. lift capacity at ball ends (kg)

5500

T5.130 DYNAMIC COMMAND™

Max. horsepower - ISO TR14396- ECE R120 [kW/hp(CV)]

96/130

Max. lift capacity at ball ends (kg)

5500

T5.140 DYNAMIC COMMAND™

Max. horsepower - ISO TR14396- ECE R120 [kW/hp(CV)]

103/140

Max. lift capacity at ball ends (kg)

5500

T5.140 AUTO COMMAND™

Max. horsepower - ISO TR14396- ECE R120 [kW/hp(CV)]

103/140

Max. lift capacity at ball ends (kg)

5500

Technical specifications


Engine*
Engine*
No. of cylinders / Capacity / Valves / Compliant emissions regulations
Max. horsepower - ISO TR14396- ECE R120 [kW/hp(CV)]
Rated horsepower (Rated speed @2200rpm) - ISO TR14396- ECE R120 [kW/hp(CV)]
Max. torque - ISO TR14396 (Nm)
Diesel tank capacity / AdBlue tank capacity (Litres)
Electrical 12 volt alternator Standard / Optional
Dynamic Command™ 8 step semi-powershift transmission
Auto Command™ continuously variable transmission
Standard Class 1.5 HD Front Axle
PTO engine speed
Standard Hydraulic Main Pump 80Lpm flow / 200 bar Pump pressure
Electronic Draft Control (EDC)
Four pillar 360° Horizon™ cab with FOPS - OECD Code 10 Level 1
Dimensions

* Developed by FPT Industrial
** @1600rpm
