T4 N
STYLISH NEW T4F/N/V. GREAT LOOKS, BRILLIANT PERFORMANCE.

T4 N

white dots
POWERFUL AND COMPACT Powered by all-new four-cylinder engines and with the addition of the flagship T4.105 model producing 106hp, the T4 F/N/V tractor series offers unrivalled performance in a compact package.
SPECIALIST VERSATILITY Few specialist tractors can match the all-round versatility of a T4 F/N/V tractor.
PRODUCTIVE COMFORT Available with an advanced category 2 Blue Cab for superior operator protection, T4 F/N/V tractors match unrivalled comfort in the most unforgiving environments with brilliant all-round visibility.
ENGINEERED TO REDUCE COSTS Long engine service intervals and low fuel consumption reduce the whole life operating costs of all T4 F/N/V models.
T4 N

STYLISH NEW T4F/N/V. GREAT LOOKS, BRILLIANT PERFORMANCE.

Offered in three widths to suit a range of specialist applications, the T4F/N/V tractor series match high power to weight ratios to best in class manoeuvrability. Key features include power outputs of 65, 78, 88, 97 and 106hp(CV), a wide transmission offering, cab or ROPS and a choice of front axles.

Features

  • THE RIGHT FRONT AXLE FOR YOUR NEEDS

    All T4V/N/F tractors can be specified with a choice of 2WD or 4WD front axles. T4N/F are also available with a tight turning 4WD SuperSteer™ front axle. The turn radius of the 2WD drive T4F/N/V tractors can be as low as 2.8m. The 2WD specification is available on both ROPS and cab models.
  • COMPACT FOUR-CYLINDER POWER

    With torque as high as 425Nm and torque reserves of up to 46%, T4F/N/V tractors bring massive performance to a compact tractor package. Developed by FPT Industrial, the Tier 3 power units are smooth running, fuel efficient and quiet. Proven in existing T5000 and T6000 tractors, these engines have long service intervals to minimise operating costs.
  • A WIDE CHOICE OF EFFICIENT TRANSMISSIONS

    Thanks to the modular build of T4F/N/V tractors, the transmissions can be easily matched to end user needs. Advanced features include powershuttle, power clutch, park lock and creep speed options. To cope with the extra power of the new T4.105, a heavier duty clutch and stronger rear PTO driveline components are used.
  • DESIGNED AROUND THE OPERATOR

    Operator comfort is a key New Holland priority. State of the art virtual simulation technology is employed to achieve the most ergonomic layout of the cab controls. This has resulted in an all new right hand console design, grouping all main hydraulic levers together for ease of operation. Noise and vibration levels are tightly controlled, with light steering and class leading visibility over the stylish engine hood all contributing to reduced operator fatigue.
  • SPECIALIST TRACTORS FOR SPECIALIST NEEDS

    The modular build of T4F/N/V tractors enables New Holland to offer a broad range of specifications that exactly matches your specialised need. The standard hydraulic flow of all models is 48.6Lpm. Need more flow? Specify the Megaflow pump, and output can be increased to 63.8Lpm. T4F/N/V. Factory built to your specification.
  • UNIQUE NEW HOLLAND FEATURES FOR PRODUCTIVITY AND SAFETY

    SuperSteer™ front axles with Auto 4WD management and dedicated front hitch are unique to New Holland. Offering an effective steering angle of 76°, tractor with a SuperSteer™ front axle can offer a turn radius as low as 2.9m for truly outstanding agility. The way in which the axle moves as the steering lock is increased helps to reduce front wheel scrub.
MODELS

Explore available models

T4 N

T4.75N

Rated Engine Power ISO TR14396 - ECE R120 [kW/hp(CV)]
57/78
Transmission
16 x 16 Shuttle Command™
T4 N

T4.85N

Rated Engine Power ISO TR14396 - ECE R120 [kW/hp(CV)]
65/88
Transmission
16 x 16 Shuttle Command™
T4 N

T4.95N

Rated Engine Power ISO TR14396 - ECE R120 [kW/hp(CV)]
71/97
Transmission
16 x 16 Shuttle Command™
T4 N

T4.105N

Rated Engine Power ISO TR14396 - ECE R120 [kW/hp(CV)]
78/106
Transmission
16 x 16 Shuttle Command™

Technical specifications

New Holland Engine*

New Holland Engine*
No. of cylinders / Capacity / Valves / Emissions Level
Aspiration
Intercooler
Approved biodiesel Blend
Rated Engine Power ISO TR14396 - ECE R120 [kW/hp(CV)]
Rated Engine Speed (rpm)
Max. Torque ISO TR14396 (Nm)
Torque reserve (%)
Horizontal Exhaust
Vertical exhaust (Cab only)
Internal EGR
Cooling method
Optimum fuel Consumption (g/kWh)
Fuel tank capacity standard front axle (L)
Fuel Tank capacity SuperSteer™ front axle (L)
Service Interval (hrs)

Transmission

16 x 16 Shuttle Command™ (30kph / 40kph)

28 x 16 Shuttle Command™ [Optional Creeper (30kph / 40kph)]

32 x 16 Split Command™ (30kph / 40kph)

16 x 16 Powershuttle (30kph / 40kph)

32 x 16 Dual Command™ (30kph / 40kph) and parking lock

44 x 16 Dual Command™ [Opt. Creeper (30kph / 40kph)] and parking lock

Front axle

Hydraulic system

PTO

Operator environment

Dimensions & Weights***

* Developed by FPT Industrial
** Conditions apply
*** Rear Tyres T4N = 320/85R24
**** With driver (85kg) and full fuel tank
