Combine Harvester TC
GREAT LOOKS. BRILLIANT PERFORMANCE.

TC

white dots
EXCELLENT CAPACITY With four or five straw walkers with up to 6.69m² of separation, all the new TC combine models guarantie great productivity.
GREAT HARVEST QUALITY The three-stage Cascaded cleaning system features a 450mm sloping pre-sieve, the adjustable fan forcing air through the grain to remove chaff and short straw ahead of the top and bottom-sieves.
EASE OF OPERATION Integrated into the seat, the adjustable side console puts every major control within easy reach.
ABSOLUTE DRIVING PLEASURE New Holland has invested thousands of hours in developing and improving the operator’s environment.

TC

The new TC combine series delivers dependable performance in varied crops and conditions. It also offer great output without compromising straw or sample quality. Then there is the all-new Harvest Suite™ Comfort Cab. This sets new and class leading levels of comfort and visibility. Of equal importance, a wide specification choice means there is a model to match your specific needs.

Features

  • A COMBINE DESIGNED AROUND YOUR SPECIFIC NEEDS

    Thousands of operators, all around the world, have found the TC combine range to far exceed their expectations. The productivity of the TC combine range is a perfect match for the requirements of mixed and small scale arable farmers where value and reliability is key. New, cleaner ECOBlue™ HI-eSCR 2 Stage V power units are engineered to treat only the exhaust gases of the TC Combine, optimizing fuel consumption, giving real savings to the owner. The all new Harvest Suite™ Comfort Cab puts the operator in the best position, providing a relaxed environment for those long harvesting days. Mounted on rubber isolation blocks, the Harvest Suite™ Comfort Cab provides enhanced smoothness and noise levels as low as 74dB(A). The attractive styling combined with large access panels not only provides class leading service access, but also reflects the all round professional package of the TC range.
  • OVER 20 YEARS OF DEVELOPMENT AND MORE THAN 50,000 COMBINES

    New Holland TC combines have an unrivalled pedigree, with over 20 years of development invested in the new TC series. Over 50,000 TC combines have been produced since the first machine was built in 1992. The proven New Holland heritage and design DNA of all these machines has been inherited by the new TC range. Hydrostatic drive, Rotary Separator, self-levelling sieves, high comfort cab, multi-function controller and automated header control are all part of TC combine development history. The new TC combine models have evolved in line with your changing needs. All our expertise and user experience comes together in these new models. When productivity and reliability count, you can depend on us.
  • NEW HOLLAND GRAIN HEADERS FOR PEAK TC PRODUCTIVITY

    TC productivity starts at the header. Common grain header features include a large diameter reel, with easy adjustment, an aggressive knife action and retractable fingers over the full intake auger width. These features combine to deliver consistent crop feed right from the start. You can get working faster too, thanks to the quick header coupling system and, if you have to stop for a blockage, no problem. Blockage clearance is straightforward and dependable. Just what you expect from New Holland.
  • DUAL OR TRIPLE-DRUM THRESHING LOOKS AFTER GRAIN AND STRAW

    New Holland TC combines match performance and productivity with high sample quality and gentle straw handling. Where straw is baled for feed or bedding, a standard TC combine will deliver a well-presented swath of unbroken straw. Need increased threshing performance? With the Rotary Separator option you have a more aggressive forced separation system, ideally suited to high throughput in heavy crops.
  • CLEAN SAMPLES, EVEN ACROSS SLOPING TERRAIN

    Working over sloping terrain? New Holland has the answer with its Smart Sieve™ with Opti-Fan™ option. Designed to minimise crop losses and enhance cleaning across slopes of up to 25%, Smart Sieve™ works completely automatically, delivering consistent sample quality day in, day out. For level land, the standard fixed cleaning shoe system features a steeply sloping 450mm long pre-sieve in addition to a top and bottom sieve for a generous total cleaning area of 4.32m2. TC combines match productivity with the ability to deliver exceptional sample quality.
  • HIGH CAPACITY GRAIN TANKS MATCHED TO FAST UNLOADING

    A key harvest frustration is to have a full grain tank with no trailer support. With a 5200 litre tank on the TC5.70 and 6400 litres on the TC5.90, TC series combines have the capacity to keep working for longer. And when the trailer does arrive, the tanks can be emptied in under 2 minutes.
  • CHOP OR BALE, WE’VE GOT IT COVERED

    Gentle residue management is a core TC combine feature, the straw swath produced by these models suits all types of baler. For those who do not wish to bale, a fully integrated Dual-Chop™ straw chopper is available. This will produce a fine chop to help speed the breakdown of residues. High quality bales or fine chopping, the choice is yours.
  • HARVEST SUITE™ COMFORT CAB. SETTING THE NEW STANDARD FOR OPERATOR COMFORT

    Each new generation of New Holland TC combine has benefitted from developments to enhance operator comfort. With the all-new Harvest Suite™ Comfort Cab, the New TC range takes a step into a new chapter in operator comfort. Quieter, with class leading visibility, the new cab is more spacious and better equipped. Of equal importance, the CommandGrip™ handle introduces the next generation of controller to this combine sector.
  • NEW HOLLAND LOGIC BASED ON CUSTOMER FEEDBACK

    Over generations of tractors, forage harvesters and combines, New Holland has used customer feedback to refine and improve its controls. TC series combines are right at the top of the latest innovative thinking. Initially unfamiliar buttons quickly identify their function, logical positioning placing the most used features at the operator’s fingertips.
  • A WINNING COMBINATION

    The TC range of combines benefits from the productivity enhancing features of FPT Industrial 4.5L & 6.7L NEF engines equipped with ECOBlue™ HI-eSCR 2 technology for Stage V compliance. Through the Clean Energy Leader strategy, New Holland is committed to making agriculture more efficient while respecting the environment. The proven ECOBlue™ technology uses AdBlue to transform the harmful nitrogen oxides contained in the exhaust gas into harmless water and nitrogen. This after-treatment system is separate from the engine which means the engine only breathes clean, fresh air. This means clean running power units that offer improved performance and enhanced fuel economy.
  • YOUR AFFORDABLE ACCESS TO PRECISION FARMING PRACTICE

    Reduced inputs can go hand in hand with increased yields. This is part of the thinking behind precision farming, a practice that makes use of site specific crop data to influence subsequent seed and fertilizer applications. TC combine models are factory ready to receive a range of different systems to support precision farming.
  • COMPACT COMBINING

    The TC4.90 model is at the pinnacle of four strawwalker combine development, never has so much technology and comfort been combined into such a small package. Borrowing the same features and technology as its bigger brothers, the TC4.90 offers high performance and productivity for small and mid sized businesses, and where compact dimensions and field accessibility are key factors.
  • 360°: TC

    The new TC range has been designed to spend more time working and less time in the yard. After all, we all know how precious time in the field is during short harvesting seasons. All service points are easy to access, and long service intervals mean your machine will spend more time in the field.
MODELS

Explore available models

 TC4.90

TC4.90

High-Capacity grain header (m)
3.96 - 4.57 - 5.18 - 6.10****
Number
4
TC5.70

TC5.70

High-Capacity grain header (m)
3.96 - 4.57 - 5.18 - 6.10****
Number
5
 TC5.90

TC5.90

High-Capacity grain header (m)
3.96 - 5.18 - 6.10 7.32 - 9.14*****
Number
5

Technical specifications

Cutting width

High-Capacity grain header (m)
High-Capacity rice header (m)
Heavy Duty Varifeed™ grain header (575mm of knife travel) (m)
Knife speed Standard/Varifeed (cuts/min.)
Spare knife and spare bolted knife sections
Feeding auger with full-width retractable fingers
Reel diameter (m)
Electro-hydraulic reel position adjustment
Instant tine angle adjustment
Headland routine sensors
Fast coupler
Triple PTO

Maize headers

Header control systems

Straw elevator

Cab

Threshing drum

Drum concave

Beater

Rotary Separator

Strawwalkers

Cleaning

Cleaning fan

Return system

Grain elevator

Graintank capacity (l)

Unloading auger

Engine

Fuel tank

Transmission

Residue management

Weights

Dimensions

* Developed by FPT Industrial
** Biodiesel blend must fully comply with the latest fuel specification EN14214:2009 and operation is in accordance with operator manual guidelines
*** Wide version, 620/75R30, 2WD, no spreader
**** 3rd lift cylinder is obligatory, only on light crops
***** 3rd cylinder is obligatory, only for light crops, Lateral Float Feeder Required
****** 3rd lift cylinder is obligatory
