BigBaler High Density Large Square Balers

BigBaler High Density Large Square Balers

white dots
HIGH-DENSITY PERFORMANCE BigBaler 340 High Density balers can deliver up to 22% higher-density bales than other conventional large square balers, and up to 15% more when compared to BigBaler 340 PLUS models.
SMOOTH BALER ENGAGEMENT Exclusive SmartShift™ gearbox features two-speed start-up technology for smooth baler engagement while protecting the tractor’s driveline.
HYDRAULIC AXLE SUSPENSION Provides excellent ground following ability and superior accessibility underneath the baler.
STRONGER KNOTS Patented Loop Master™ knotter system increases overall bale tensile strength up to 26% for lower operating costs while eliminating twine offcuts.
BigBaler High Density Series

ALL-OUT EFFICIENCY

True to its name, the BigBaler 340 High Density packs more crop into every bale. Put into numbers, the BigBaler 340 High Density can deliver up to 22% higher-density bales than other conventional large square balers, and up to 15% more when compared to a BigBaler 340 PLUS.

Features

  • IMPROVED PRODUCTIVITY AND DURABILITY

    The standard poly tine bands provide low friction and a flat surface for smoother crop flow and quieter operation. Additionally, their flexibility and high wear resistance extend the life of the tines, which means less maintenance for you. For even greater durability on the roughest terrain or when quickly baling windrows, heavy-duty gauge wheels are available with your choice of fixed or castering arm designs.
  • BENEFITS OF SHORTER PARTICLE LENGTH

    Cutting crop as it’s fed into the baler delivers shorter particle lengths, which results in tighter material packing and greater bale density. Cutting material with up to 29 spring-protected knives can help improve silage bale fermentation, feed digestibility, bale breakup and mixing, and material absorbency. Added density can also mean more weight per bale and more tons per truck, providing even greater savings.

  • RELIABLE PACKER FEEDING

    The high-capacity packer model features three, three-tine packer forks made of Hardox®-brand steel that deliver performance, durability, and wear resistance. To match the baler's high throughput, the packer driveline is upgraded to handle up to 25% more power than BigBaler PLUS models.
  • HIGH-DENSITY PERFORMANCE

    The BigBaler 340 High Density can deliver up to 22% higher-density bales than other conventional large square balers, and up to 15% more when compared to the BigBaler 340 PLUS.
  • HEAVY-DUTY FRAME

    A new, even more robust frame has been designed to withstand higher-density loads created by the baler. The new main gearbox is mounted to the top beam to reduce crop accumulation underneath and increase durability. Additionally, the drawbar is not part of the main frame to facilitate height adjustment via the dedicated height adjustment rods, which is convenient when baling with different tractors.
  • START WITH THE PLUNGER BACK

    High density does not mean hard starting. When the machine is stopped, the smart brake stops the plunger away from the bale face. Since the plunger does not press on the bale face at startup, initial harsh-starting torque loads are virtually eliminated.
  • STRONGER KNOTS AND FEWER BROKEN BALES

    Delivering up to a 26% increase in overall tensile strength for reduced breakages, the Loop Master™ double knotting system forms the first knot in each bale with a loop style, which is 37% stronger compared to a standard or conventional large square baler knot. Perhaps more importantly, this knotting system eliminates twine offcuts, resulting in cleaner fields and feed – a great advantage for export hay producers. This system saves nearly four miles of twine for every 10,000 bales.

  • SUPERIOR DAY AND NIGHT VISIBILITY

    When you partner a BigBaler 340 High Density baler with a New Holland high-horsepower tractor, you can get 360° LED lighting to maintain your productivity, safety, visibility, and ease of operation, even in the middle of the night.
  • MYPLM® CONNECT

    MyPLM Connect enables you to connect to your BigBaler 340 High Density from the comfort of your office and monitor and features over 27 operating parameters through the utilization of the mobile network. You can stay in touch with your machines at all times and even send and receive real-time information, helping to save you time and enhance your productivity.

    The Farm tab on the MyPLM Connect portal is where you can analyze all field data transferred on the MyPLM Connect network. Even better, you can map bale data. This information is recorded in real time while baling, then automatically uploads via the connected vehicle. This data is also available on the MyPLM Connect Farm mobile app, which can be used by a telehandler or loader tractor operator to selectively load bales. When equipped, the moisture, weight, location, density, and flake count are recorded for each bale.

  • WIDE-OPEN SERVICING

    For easy servicing, a single-piece, two-stage front hood easily glides open on gas struts. The shield opens partially for fast access to all service points, or fully for complete access to all areas for cleaning.
MODELS

Explore available models

TECHNICAL SPECIFICATIONS
hay-tools-equipment-bigbaler-340-hd

BigBaler 340 High Density

Width in. (cm)
47 (120)
Height in. (cm)
35 (90)
hay-tools-equipment-bigbaler-340-hd

BigBaler 340 High Density CropCutter® Rotor Cutter

Width in. (cm)
47 (120)
Height in. (cm)
35 (90)

Technical specifications

Bale Dimensions

Width in. (cm)
Height in. (cm)
Minimum / Maximum length in. (cm)

Tractor Requirements

Main Drive

5 Bar MaxiSweep™ Pick-up

Packer Feeding System

CropCutter® System

Pre-Compresstion Chamber & Stuffer

Plunger

Tying System

Bale Density System

Precision Farming Solutions

Lights

* Depending on spec and required for Comfort pack
**Pneumatic brake version only
