T4 F/V Fruit and Vineyard tractors
GO WHERE NO OTHER TRACTOR CAN GO.

T4 F/V

white dots

CLEAN POWER The entire T4 F/V range complies with Stage V emission standards; delivering sustainability and reduced carbon footprint.

COMPACT DESIGN A winning combination of stability, power and maneuverability. Unmatched 76° turns with SuperSteer™ axle versions.

SUPERIOR SAFETY The Blue Cab™ 4 delivers the highest level of protection against contaminants on the market, featuring an exclusive double filtration system that can be raised from Level 2 to Level 4 protection.

COMFORT AND VISIBILITY Flat deck, more interior space, and new ergonomics layout controls with the lowest sound level will make long working days a pleasure.

T4 F/V

BOLD. POWERFUL. NARROW.

As the world’s leading supplier of narrow tractors, New Holland T4 Fruit and Vineyard tractors combine more power and a sleek style with enhanced ergonomics, advanced driver safety and powerful new hydraulic options. These tractors are developed to do all jobs in any condition, making the impossible possible.

Features

  • POWERFULLY EFFICIENT

    T4 F/V tractors feature the renowned F34 and F36 high-performance 4-cylinder Fiat Powertrain Technologies (FPT) Industrial engines, equipped with Stage V electronic fuel injection, offering a power range of 75 to 120hp. The F34 and F36 engines offer fantastic fuel efficiency thanks to the ability to achieve max torque at just 1,300 rpm. The AdBlue and fuel tanks are perfectly sized for long working days. FPT Industrial engines provide market leading performance and reliability. With 600 hour oil change intervals, the T4 Specialty range delivers a low cost of ownership and a reduction in downtime.

  • MORE TRANSMISSION CHOICES

    The modular design of the T4F and T4V give you a choice of transmissions to suit your needs. The driveline has been redesigned to fit all models from T4.80 to T4.120 and provide more comfort during long working days and greater reliability thanks to the wet clutch. Advanced optional technology features include Dual Command™ Hi-Lo, Power Clutch push-button, Park lock system, creeper and the famous Powershuttle. The configurable Powershuttle has 3 pre-set modes: soft, medium or hard and is easily selected at the touch of a button.

  • ALL THE HYDRAULIC POWER YOU NEED

    T4 F/V tractors provide an ample supply of hydraulic power and front and rear hitch options so you can take advantage of large implements. The Lift-O-Matic™ hitch control makes lifting and lowering implements as easy as flipping a switch.

  • AXLE OPTIONS FOR EVERY APPLICATION

    T4 F/V tractors have the option of 3 different front axles: Standard, SuperSteer™ and Terraglide™. The SuperSteer front axle offers a steering angle of 76°, giving you the advantage of the shortest FWD row-to-row turning available.

    Terraglide front axle suspension offers an incredible level of comfort for the driver all while protecting the tractor and mounted implements from rough terrain, especially during transport.

  • OPERATOR FRIENDLY

    Take your choice of an open platform or one of the two Blue Cab™ options that offer different levels of operator protection to meet the needs of different applications. Both cab and open platform models feature isolation mounting for a smooth ride and less vibration. Upgraded instruments and controls provide maximum comfort and ergonomics.
MODELS

Available Models

T4.80F tractor model

T4.80F

Engine
74 gross engine hp / 65 PTO hp
Minimum overall width
61.7 in (1569 mm) (varies by tire size)
T4.90F tractor model

T4.90F

Engine
84 gross engine hp / 75 PTO hp
Minimum overall width
61.7 in (1569 mm) (varies by tire size)
T4.100F tractor model

T4.100F

Engine
98 gross engine hp / 86 PTO hp
Minimum overall width
61.7 in (1569 mm) (varies by tire size)
T4.110F tractor model

T4.110F

Engine
106 gross engine hp / 93 PTO hp
Minimum overall width
61.7 in (1569 mm) (varies by tire size)
T4 F/V Tractor model with cab

T4.120F

Engine
120 GROSS ENGINE HP
Minimum overall width
54.33 in (1380 mm) (VARIES BY TIRE SIZE)
T4.80V tractor model

T4.80V

Engine
74 GROSS ENGINE HP / 65 PTO HP
Minimum overall width
43.1 IN (1094 MM) (VARIES BY TIRE SIZE)
T4.90V tractor model

T4.90V

Engine
84 GROSS ENGINE HP / 75 PTO HP
Minimum overall width
43.1 IN (1094 MM) (VARIES BY TIRE SIZE)
T4.100V tractor model

T4.100V

Engine
98 GROSS ENGINE HP / 86 PTO HP
Minimum overall width
43.1 IN (1094 MM) (VARIES BY TIRE SIZE)
