Next Generation CR Series Twin Rotor® Combines

The CR10 is powered by a 12.9-liter Cursor 13, producing up to 635 hp. The CR11 is powered by a 15.9-liter FPT Cursor 16, producing up to 775 hp. On both models, harvesting engine speed is 1,900 rpm for maximum capacity with minimal noise and fuel consumption. Spend less time refueling with the 343-gallon fuel tank in the CR10 or the 396-gallon tank in the CR11. Additionally, both the CR10 and the CR11 have generously-sized 48-gallon DEF tanks.

New Holland CR10 and CR11 combines are equipped to handle your highest crop volumes with driveline and clean grain elevator options designed to perfectly match their capacity. A new reengineered driveline provides greater capabilities even in your most challenging crops. Three available feeder driveline options allow you to tailor your machine to the needs of your operation for optimal feeding. The clean grain elevator has also evolved to match capacity demands, with options offering maximum throughput of up to 10,000 bushels per hour.

We’ve taken our original Twin Rotor® technology to the next level in the CR10 and CR11. New 24-inch diameter rotors are 142 inches long for more crop rotations and greater grain savings. They are mounted in a wider and longer threshing compartment, resulting in gentle grain separation and maximum straw protection. A no-maintenance CVT drive offers precision control of rotor speed and reversing, and optimal flow of crop material from the Dynamic Feed Roll™ into the Twin Rotors further reduces likelihood of damage. A fully automated de-slugging procedure easily clears blockages to protect your valuable time.

The new TwinClean™ cleaning system uses an innovative combination of increased cleaning area and automation technology to boost throughput and minimize grain loss regardless of condition or terrain. TwinClean can compensate for uneven feeding and side slopes up to 28%. Meanwhile, IntelliSense™ combine automation also monitors the graincam and controls fan speed and sieve openings to ensure minimal losses and premium sample quality.

The CR10 boasts a standard grain tank capacity of 455 bushels, while the CR11 offers an additional 25% for 567 bushels, larger than anything else currently on the market. A new elevator boasts capacity of up to 10,000 bushels per hour with the optional high speed drive kit, and both machines are capable of unload rates up to 6 bushels per second. This expanded capacity reduces total daily unload cycles, taking pressure off your operator team and allowing you to stay focused on harvesting.

The CR10 and CR11 feature completely new residue management capabilities to match the high intake volumes from the wider headers they work with. However light or dense the crop, these combines will process material finely and redistribute evenly over 60 feet. CR10 and CR11 combines can be equipped with New Holland’s award-winning IntelliSpread™ radar spread pattern monitoring, which automates spreading control to ensure full and even residue coverage behind the combine.

Our Harvest Suite™ Ultra cab provides a comfortable space with all the necessary controls and conveniences within reach. With unmatched visibility, premium seating, convenient features and a focus on comfort, operators can confidently tackle the longest harvest days. Plus, full control of the harvest is in easy reach thanks to dual IntelliView™ 12 displays that allow for efficient monitoring of critical harvest and machine functions, and a complete set of remote control functions accessible on the armrest.

Achieve optimal efficiency and productivity with the help of New Holland precision solutions:

• Increase productivity and reduce loss with IntelliSense™ combine automation
• Achieve repeatable sub-inch accuracy with IntelliSteer™ autoguidance, and add IntelliTurn to automate end-of-row turning
• Maximize fleet efficiency with IntelliField™ vehicle-to-vehicle communication
• Monitor and capitalize on key nutrient and moisture parameters with NutriSense™ NIR technology
• Make the most of your time in and out of the field with the FieldOps™ farm management platform

CR10 and CR11 combines can be equipped with a range of tire and track configurations to meet the needs of every operation. Optional SmartTrax™ front track units reduce the ground pressure exerted by comparable tires by 57%, while boosting traction and keeping transport width to a minimum. A first for the combine market, new CR10 and CR11 machines can be equipped with VF710/70 R42 and VF800/70 R38 duals to further reduce ground compaction while increasing traction.
