Direct Cut Auger Heads
LEADING FROM THE FRONT

Direct Cut Auger Heads

Direct Cut Auger Heads

CUTTING-EDGE HARVESTING PERFORMANCE

New Holland offers a complete selection of direct-cut heads, providing you with the versatility to match your crops and your operational needs. High-capacity rigid and flex heads deliver fast, clean cutting in tough field conditions, as well as reliable feeding, even in the heaviest crop conditions.

Features

  • RELIABLE. EFFICIENT. PRODUCTIVE.

    720CG High-Capacity grain headers are perfect for small- to medium-sized operations, or those who work in smaller fields. These traditional headers are easy to use and are ideal for operations which predominately harvest the same types of crop, such as wheat, oat and barley. A high-capacity header is also ideal for harvesting rice. With their tried and tested robust cutterbar table, they offer unsurpassed reliability.
  • FLEXIBILITY FOR PRECISE HARVESTING EFFICIENCY

    If you harvest in undulating terrain, the 740CF direct-cut SuperFlex™ auger head is the natural choice. Available in cutting widths of 25, 30, and 35 feet, 740CF heads feature a patented, rubber spring flotation system that allows heads to follow ground contours more closely so you get every bit of your crop. The SuperFlex knife bed flexes a full 4.5 inches to ensure a close cut and uniform stubble height in uneven fields.
  • ADAPT TO ALL TYPES OF CROP

    For optimum harvest quality and a uniform cut in different crop heights, including tall, bushy, direct-cut canola, the Varifeed™ grain head is your perfect partner. The 30, 35, and 41 Ft. models allow you to harvest at high field speeds to make full use of the high capacity of New Holland combines
MODELS

Explore available models

TECHNICAL SPECIFICATIONS
combines-740cf-superflex

740CF SuperFlex - 25 ft.

Cutting width (ft)
25
Knife speed (cuts/min.)
1,300
combines-740cf-superflex

740CF SuperFlex - 30 ft.

Cutting width (ft)
30
Knife speed (cuts/min.)
1,300
combines-740cf-superflex

740CF SuperFlex - 35 ft.

Cutting width (ft)
35
Knife speed (cuts/min.)
1,300
combines-760cg-varifeed

760CG Varifeed - 30 ft.

Cutting width (ft)
30
Knife speed (cuts/min.)
1,300
combines-760cg-varifeed

760CG Varifeed - 35 ft.

Cutting width (ft)
35
Knife speed (cuts/min.)
1,300
combines-760cg-varifeed

760CG Varifeed - 41 ft.

Cutting width (ft)
41
Knife speed (cuts/min.)
1,300

Technical specifications

Specifications

Cutting width (ft)
Knife speed (cuts/min.)
Knife stroke (in.)
Knife drive
Spare knife and spare bolted knife sections
Dual knife drive
Knife travel (in)
Vertical knife flexibility (in.)
Feeding auger with full-width retractable fingers
Spare knife
Auger speed (rpm)
Hydraulic reel drive
Distance between knife and in take auger (in)
Autofloat™ system
Medium divider
Weight (lbs)
Plate point short divider
Long divider
Stub guards
